TrailMaster 163cc Kids XRX-R+ Go Kart (Automatic with reverse Clutch, 5.5 HP General Purpose Engine, Electric Start with pull backup system, 12.4 mph top speed)
SKU: TM-MINI-XRX-R-Plus
Availability :
In Stock
Pre order
Out of stock
Specification
Dimension
Enginedrive train
|
Carb ca only Green Sticker Certification |
|
Epa Yes |
|
Hot item Hot Item |
|
Kidsyouth adult go kart Youth Go Kart |
|
Weight 209.0000 |
| Clutch | Automatic w/Reverse |
|---|---|
| Driveline / Driving wheel | Chain / Dual wheel drive |
| Suspension, F / R | Dual A-arm / Double Oil Damped Shock |
| Brakes | Disc |
| Tires, F / R | 145X70-6 / 16 X8-7 |
Dimension
| Fuel capacity | 1.2 gal |
|---|---|
| Weight, G.W. / N.W. | 280 / 232 lbs |
| Max load | 300 lbs |
| Wheelbase | 42.6 inches |
| OA L x W x H | 58.7x38.2x48.8 inches |
| Height to seat | 13.6 inches |
| Min ground clearance | 4.02 inches |
| Pedal to seat back | 30” to 35”; Pedal can also adjusted to 3” or 6” shorter. |
Enginedrive train
| Engine type | 4-stroke, single cylinder, air cooled |
|---|---|
| Displacement | 163cc |
| Max HP | 5.5hp/3600rpm |
| Max torque | 8 lb ft/3600rpm |
| Bore x stroke | 2.6 x 1.8 inches |
| Max speed | 12.4mph |
| Climbing ability | 12 degrees |
| Ignition | C.D.I |
| Starting system | Electric Start with Pull Start Backup |
| Battery | 12V 9Ah |
| Carburetor brand | JF (RX) |
| Engine oil | SAE 15W-40 |
Description
The main differences for the Mini XRX/R+ from the Mini XRX/R is that the Mini XRX/R+ have wider frame, wider seat, extra legroom and best of all: much taller frame and bigger front and rear tires!
Kart Size Comparison
Kids Go Kart
110cc Go Kart
- Wheel Base: 52 to 56 inches
- Horse Power : 6.5+
- Max Speed: 5 to 35+ MPH
- Distance from Pedal to Seat Back: 23 to 29 inches
Kids & Youth Go Kart
150cc Go Kart
- Wheel Base: 62 to 68 inches
- Horse Power : 10.0+
- Max Speed: 5 to 35+ MPH
- Distance from Pedal to Seat Back: 31.5 to 43 inches
Youth & Adult Go Kart
200CC Go Kart
- Wheel Base: 62 to 68 inches
- Horse Power : 15+
- Max Speed: 5 to 35+ MPH
- Distance from Pedal to Seat Back: 2 to 4 inches Longer than Regular Type Go kart
Full Size Adult Go Kart
250cc Go Kart
- Wheel Base: 62 to 68 inches
- Horse Power : 20+
- Max Speed: 5 to 35+ MPH
- Distance from Pedal to Seat Back: 41 to 48 inches
